Printed Circuit Board Prototype
Printed Circuit Board Prototype
PCB prototyping used to the nightmares of many electronics professionals. YahengPcb now terminates the nightmares! We can get your first-try boards in 24 hours!
After placing your order, our engineer will audit your Gerber files to make sure it complies with our technical spec. Once the files pass the audit, you can pay the cost online. Also, our engineer will check again and optimize the files to make production.
The prototyping stage is the most critical period for engineers, students, and hobbyists. For manufacturing PCB, YahengPcb has the experience of manufacturing PCB for more than 10 years(since 2013). Choosing Yaheng Circuits can not only shorten the manufacturing time of the PCB but also reduces the cost and get the high-quality boards. Our online PCB calculator will always show the cheapest price and production time.
Check YahengPcb PCB manufacturing capabilities in the following table:
| Feature | Capability |
| Min. Line Width | 0.076mm/3mil |
| Min. Hole Size | 0.15mm---1mm |
| Min. Line Spacing | 0.076mm/3mil |
| Copper Thickness | 1oz---13oz |
| Base Material | Aluminum, FR4, Flex, Flex-rigid, HDI, Rogers, etc. |
| Board Thickness | 0.2,0.4, 0.6,0.8,1.0,1.2,1.6,2.0,2.4 mm |
| Surface Finishing | HASL with lead HASL, Lead-free, Immersion gold, OSP, Hard Gold |
| Finsih Cooper | 1-13oz |
| Solder Mask | Green, Red, Yellow, Blue, White, Black, Purple, Matte Black, Matte green |
| Silkscreen | White, Black |
| Testing | Fly Probe Testing (Free) and A.O.I. testing |
| Build time | 24 hours |
| Lead time | 2-3 days |
